Technical Specifications
| Protocol | EPC global UHF Class 1 Gen 2 / ISO 18000-6C |
| Frequency | EU 840 MHz to 868 MHz or US 902 MHz to 928 MHz or customized Fixed or FHSS |
| Support Tags | Normal RFID tags; Temperature sensor; Moisture sensor RFID tag |
| RSSI Testing | Support |
| RF Power | 30 dBm ± 1 dB (Max) |
| Step Power | 1 dBm |
| Channel Occupied Bandwidth | < 250 KHz |
| Antenna | Built-in 8 dBi circular polarized antenna |
| Effective Distance | 8 dBi circular polarized antenna, 30 dBm, standard testing tag Read: 32.8 ft (10 m) Write: 13.1 ft (4 m) |
| Reading Speed | 100 tags per s (SR-RU120) |
| Interface | RS232, RS485, Weigand 26/34 and Trigger |
| RJ45 and WIFI are optional | |
| Baud Rate | 115200 bps |
| Operating Voltage | +12.0 V |
| Operating Current | ≤ 0.7 A |
| Standby Current | ≤ 100 mA |
| Operating Temperature | -4 °F to 131 °F (-20 °C to +55 °C) |
| Storage Temperature | -22 °F to 185 °F (-30 °C to +85 °C) |
| Operating Humidity | < 95 % RH 77 °F (+25 °C) Non-condensing |
