Features
- Compact shock-proof design
- Integrated multi-functions
- High storage capacity
- Long battery life
Technical Specifications
| Wavelength | 1310nm/1550nm ±20nm |
| Fiber Type | G.652 SM Fiber |
| Dynamic Range | 24 dB/22 dB |
| Event Blind Zone | 9.8 ft (3 m) |
| ATT Blind Zone | 26.2 ft (8 m) |
| Test Range | 1640 ft to 37.3 mi (500 m to 60 km) |
| Pulse Width | 3 ns to 10 μs |
| Ranging Accuracy | ± (3.28 ft + Sampling Interval + 0.005% × Test Distance) |
| Loss Accuracy | ±0.2 dB/dB |
| Sampling Points | 16k to 128k |
| Sampling Resolution | 2 in to 26 ft (0.05 m to 8 m) |
| Reflection Accuracy | ±3 dB |
| Data Storage | Internal: ≥600; External: TF Card |
| Laser Safety Level | Class II Level |
| File Format | SOR Standard File Format |
| Connector | FC/UPC (Interchangeable SC ST) |
| Wave Range | 800 nm to 1700 nm |
| Interface Type | Universal Joint FC/SC/ST |
| Test Range | -50 dBm to +26 dBm |
| Uncertainty | ±5% |
| Frequency Identification | CW/270/330/1k/2kHz |
| Calibration Wavelength | 850/980/1300/1310/1490/1550/1625/1650 nm |
| LD Type | FP-LD |
| Output Wavelength | 1550 nm ±20 nm, 1310 nm/1550 nm ±20 nm |
| Output Power | ≥-5 dBm |
| Modulation | 270/330/1k/2kHz |
| Work Wavelength | 650 nm ±20 nm |
| Output Power (VFL) | ≥10 mW |
| Mode | CW/1Hz/2Hz |
| RJ45 Test Range | 984 ft (300 m) |
| Display | 3.5 inch Color LCD |
| Data Interface | Micro USB |
| External Storage | TF Card |
| Power Supply | Polymer Li-Battery: 3.7V, 4000mAh; Adapter: 5VDC, 2A |
| Battery Life | Standby >20 h; Measuring time >12 h |
| Operating Temperature | 14 °F to 122 °F (-10 °C to +50 °C) |
| Storage Temperature | -40 °F to 158 °F (-40 °C to +70 °C) |
| Relative Humidity | 0 to 95% Non-condensing |
| Weight | 12.35 oz (≤350 g) |
| Dimension | 6.8 × 3.2 × 1.5 in (17.3 × 8.2 × 3.7 cm) |
