Technical Specifications
| Power Supply | 12 to 24 VDC or AC220V |
| Power Consumption | 2 W |
| Working Frequency | 470 MHz to 510 MHz |
| Maximum Transmitting Tower | 19 ± 1 dBm |
| Modulation Method | LoRa |
| Reception Sensitivity | -136 dBm ± 1 dBm (@ 250 BPS) |
| Communication Rate | 0.2 Kbps to 37.5 Kbps |
| Antenna | Omni-directional FRP antenna (470-510 MHz) |
| Ports Specification | RJ45 |
| Baud Rate | 9600 |
| Network Protocol | IP, TCP/UDP, IPv4 |
| IP Acquisition Mode | Static IP, DHCP |
| DNS | Supported |
| Web Caching | TX: 6 Kbyte, RX: 4 Kbyte |
| Standard Spectrum | 850/900/1800/1900 MHz |
| Transmission Power | GSM900 class 4 (2 W) |
| DCS1800 Class | 1 W |
| Working Mode | Transparent transmission |
| TCP Connections | 2 |
| Operator Compatibility | Mobile 2G, 3G, 4G; China Unicom 2G, 3G, 4G; Telecom 4G |
| SIM Card | Standard 6-pin SIM card interface, 3 V, 1.8 V |
| Protection Grade | IP65 |
| Material | Die-cast aluminum alloy |
| LoRa Private Protocol | Simple, secure, and reliable |
| Data Encryption | Supported |
| Distance Transmission | Up to 6562 ft (2000 m) |
| Ports | RS485, I2C for expansion |
| Design | Fanless, for long-term operation in rugged environments |
| Working Temperature | -40 °F to 176 °F (-40°C to 80 °C) |
| Working Humidity | 0% to 95% RH |
