Overview
A RFID reader with ISO18000-6C protocol, 6 dBi gain, and adjustable RF power. Ideal for various interfaces and operates in a wide temperature range.
Features
- Automatic scan Com Port or network
- Support Firmware Upgrade
- Support export config or import config
- Multiple Country Languages
- Global Frequency
- Password Mode
- Read Specify Mode
- Relay
- Data Cache
- Multiple Customizable communication protocols
- Remote Listening
- RSSI
Technical Specifications
| Frequency | 865 MHz to 868 MHz (EU Standard) or 902 MHz to 928 MHz (US Standard) |
| Protocol | ISO18000-6C (EPC Gen2) |
| Type | Low-cost RFID reader |
| Interface | RS232 or WG26 or RELAY or TCP or IP or POE or USB or TTL or RS485 |
| Gain | 6 dBi |
| Read Range | 19.6 ft to 22.9 ft (6 m to 7 m) (depends on tag) |
| Color | White |
| Material | ABS |
| Power Supply | 9 V to 24 V |
| Technical Support | Yes |
| Built-in Antenna | 6 dBi circular Antenna |
| Work Mode | Active or Trigger or Answer or password or mask mode |
| RF Power | 26 dBm (adjustable) |
| Interfaces | RS232 or WG or Relay or TCP or IP or POE or USB or TTL or RS485 or WIFI |
| Operating Temperature | 14 °F to 131 °F (-10 °C to + 55 °C) |
| Storage Temperature | -4 °F to 167 °F (-20 °C to + 75 °C) |
| Reader Size | 8.6 in 8.6 in 2.2 in (220 mm x 220 mm x 56.4 mm) |
| Weight | 33.5 oz (950 g) |
