Features
- Cortex-A7 CPU
- POE Power Supply
- Low Power Usage
- SF5/SF6 Support
- 64-Bit ID Tag
- Multi-Channel RX
Technical Specifications
| CPU | Cortex-A7 |
| Main Frequency | 528 MHz |
| Internal Storage | 512 MB |
| Flash Memory | 8 GB |
| Ethernet | 10 or 100M adaptive dual-network port |
| PDA | BLE 4.2 |
| Communication Mode | 4G Cat.1 |
| Wireless System | LoRa full duplex |
| LoRa Service Frequency | Domestic: 470 to 510 MHz, Multi-band options: IN 865 or RU 864 or EU868US915 or AU 915 or KR 920 or A5923 |
| 4G Operating Frequency | LTE-FDD B1 or 3 or 5 or 8, LTE-TDD B34 or 38 or 39 or 40 or 41 |
| LoRa Receive Channel | 8-way 125 KHz SF adaptive (5 to 12), Channel 1-way 125 or 250 or 500 bandwidth |
| LoRa Transmitting Power | 22 dBm |
| LoRa Reception Sensitivity | -141 dBm (SF12 & BW125KHz) |
| 4G Communication Protocol | TCP or UDP or MQTT (software configurable) |
| Data Format | Transmission or TLV or JSON (software upgradable) |
| 4G Data Rate | LTE-FDD (Downlink 10 Mbps, Uplink 5 Mbps), LTE-TDD (downlink 8.9 Mbps, uplink 3 Mbps) |
| LoRa Data Rate | 300 bps to 62.5 kbps |
| Service Voltage | DC 9 to 24 V |
| Protection Level | IP67 |
| Machine Power | 3 W |
| Work Environment | Temperature: -40 °F to 158 °F (-40 °C to 70 °C), Relative Humidity: 95% RH (no condensation) |
| Product Size | 9.25 in x 8.38 in x 2.83 in (23.5 x 21.3 x 7.2 cm) |
