Features
- Hardware encryption circuit
- Rich protocol library
- Supports IEC protocols
- Built-in web server
- Remote configuration and maintenance
Technical Specifications
| CPU | ARM 9, 300 MHz |
| Memory | 128 MB DDR3 SDRAM, 128 MB flash |
| Network Interface | 2-wire high-speed 10/100 Mbit/s |
| RS485 Interface | 2/4 wire RS485 |
| Built-in Features | RTC, temperature sensor, hardware encryption |
| Protocol Support | IEC60870-101/103/104, ProfiNET, EtherNet, BACnet, SNPx, Modbus TCP/IP, MQTT, OPC-IE |
| Web Server | Built-in, remote configuration support |
| Communication Functions | Data gateway, forwarding, protocol conversion |
| CAN Interface | Bidirectional optical isolation, CAN 2.0 |
| Serial Port Support | Debug serial port, supports WiFi, GPRS, 3G, 4G |
| Memory Expansion | 4 GB to 128 GB TF card |
| Enclosure | Rugged metal shell, three defenses treatment |
| Operating Environment | Designed for harsh conditions |
