Features
- LoRa supports 8RX 1TX channels
- Support 2.4G Wi-Fi
- 100M base T Ethernet supporting PoE
- Support Ethernet Wi-Fi or LTE uplink multi link backup
- Open WRT software program that supports LoRa WAN and network configuration
- Built-in radiator for heat dissipation
- Access to private or public (TTN) LoRa network server
- Support TF card storage method
- Suitable for use at indoor ambient temperature
- Support optional LTE 4G function support
Technical Specifications
| Application | Indoor gateway |
| Supplier Type | Indoor lora wan gateway |
| Processor | MT7628, DDR2RAM 128MB |
| Power Supply | DC 12V to 1 A |
| Power Consumption | 12W |
| Ethernet | RJ45(10/100M) |
| Console | RJ45 (RS232) |
| Supply Ability | 300000 Piece/Pieces per Year Lora wan Gateway For 4g / Ethernet /Wi-Fi Wireless Data Transmit |
| Wi-Fi Function | Frequency: 2.400-2.4835GHz (802.11b/g/n) RX sensitivity: -95dBm (minimum), TX power: 20dBm (maximum) Operating channel: 2.4GHz: 1-13 |
| LoRa Function | RX sensitivity: -142dBm (minimum), TX power: 27dBm (maximum) Frequency: EU433, CN470, EU868, US915, AS923, AU915, KR920, I |
| Mobile Cellular Network | Support optional Quectel EG95-E/EG95-NA: LTE CAT 4 network, not supported by default |
