Features
- No mechanical wear
- Excellent reliability
- Stability and consistency
- Can diagnose battery abnormality
Technical Specifications
| Medium Temperature | Cold Water |
| Counter Instructions | Digital |
| Medium Pressure | General Water Meter |
| Structure | Wireless Communicating |
| Pipe Joint | Bsp |
| Installation | Horizontal or Vertical |
| Level Measurement | B |
| Nominal Diameter | Small Diameter |
| Principle | Speed of Water Meter |
| Work Environment | Dry Water Meter |
| Environmental Class | O |
| Pressure | 1.6 MPa |
| Permanent Flowrate | 4 m³/h |
| Start Flowrate | 3 m³/h |
| Ratio | 250 |
| Accuracy | Level 2 |
| Pressure Loss | △p30 |
| Data Storage | 1 Year of Daily Data Storage, 24 Months of Historical Data. |
| Communication Interface | Infrared, M-BUS, RS485, NB-IoT, LORA, LoRaWAN, TTL, Pulse (Optional) |
| Power Supply | Lithium, DC 3.6 V |
| Power Outage Protection | After a power outage, the accumulated flow rate and corresponding time recorded before the power outage can be saved, and the metering function will be automatically restored after the power supply is restored. |
| Protection Level | IP68 |
| Electromagnetic Class | E2 |
| Life or Duration | ≥ 8 Years |
| Flow Temperature | 32.18 °F to 140 °F (0.1 °C to 60 °C) |
| Dimension | 9.65 in x 4.13 in x 7.68 in (245 mm x 105 mm x 195 mm) |
