Features
- IP67 Rating
- Quad-core CPU
- SX1302 Chip
- Backhaul connectivity
- Embedded network server
- Compatible with multiple network servers
- Global LoRaWAN
Technical Specifications
| Hardware System | CPU: Quad-core 1.5 GHz, 64-bit ARM Cortex-A53 |
| Memory | 512 MB DDR4 RAM |
| Flash | 8 GB eMMC |
| LoRaWAN | Antenna: Fully Integrated Internal (Optional: 2 x 50 Ω N-female external) |
| LoRaWAN Frequency Band | AU915 or AS923 |
| Sensitivity | -140 dBm @292bps |
| Output Power | 27dBm Max |
| LoRaWAN Protocol | V1.0 Class A or Class C, V1.0.2 Class A or Class C |
| Ethernet Interface | Port: 1 x RJ45 (PoE PD supported), 10 or 100 or 1000 Base-T (IEEE 802.3) |
| Data Rate | 10 or 100 or 1000 Mbps (auto-sensing) |
| Wi-Fi | Antenna: Fully Integrated Internal, Standards: IEEE 802.11 b or g or n |
| Power Supply | 1 x 802.3 af PoE input, 1 x 12 VDC with M12 Connector |
| Power Consumption | Typical 3.6 W, Max 4.8 W |
| Ingress Protection | IP67 |
| Ethernet Isolation | 1.5 kV RMS |
| Relative Humidity | 0% to 95% (non-condensing) at 77 °F (25 °C) |
| Operating Temperature | -40 ℉ to +158 ℉ (-40 °C to +70 °C) |
| Storage Temperature | (-40 ℉ to +185 ℉ (-40 °C to +85 °C) |
| Dimension | 9.84 in x 6.77 in x 3.62 in (25 cm x 17.2 cm x 9.2 cm) |
