Features
- G-sensor supported
- Gyroscope supported
- Tamper detection, FOTA over bluetooth support
- Battery level report and proximity detection support
Technical Specifications
| Bluetooth Protocol | Bluetooth 5.0, iBeacon |
| Bluetooth TX Power | -20 dBm to + 4 dBm, configurable in 4dB steps |
| Bluetooth Sensitivity | -96 dBm |
| Bluetooth Accuracy | 9.8 ft (3 m) |
| LoRaWAN Protocol | LoRaWAN 1.0.2B, Class A |
| Activation Mode | OTAA or ABP |
| LoRaWAN Bands | US 915, AU 915, EU 868, EU 433, AS 920 to 923, AS 923 to 925, RU 864, ID 920, KR 920, IN 865, KZ 865, CLAA, CN 470, CN470-Ali |
| LoRa TX Power | 0 dBm to 20 dBm |
| LoRaWAN Range | >0.62 mi (1 km) in urban areas |
| Encryption | AES128 |
| GNSS Band | 1575 MHz to 1610 MHz |
| GNSS Tracking Accuracy | 8.2 ft (2.5 m) |
| GNSS Cold Start | 30 s to 60 s |
| Battery Capacity | Li-ion, 1000 mAh |
| GNSS Reports (Report Interval > 10 min) | Approx. 5,000 times per charge |
| Bluetooth Reports | Approx. 160,000 times per charge |
| Housing Material | PC (Polycarbonate) |
| Ingress Protection | IP66 (Dustproof & Water Resistant) |
| Impact Protection | IK10 (High Impact Resistance) |
| Standby Current | 25 μA |
| Barometer | 3.9 in (10 cm) altitude accuracy |
| PCB Coating | Waterproof coating |
| NFC Tag | 1 KB |
| Position Report Interval | Adjustable 5 s × n (1 to 65536) |
| Heartbeat Report Interval | Adjustable 30 s × n (1 to 65536) |
| Operating Temperature | 14 °F to 140 °F (-10 °C to 60 °C) |
| Charging Temperature | 32 °F to 122 °F (0 °C to 50 °C) |
| Weight | 3.17 oz (90 g) |
| Device Dimensions | 3.15 in × 3.15 in × 1.38 in (80 mm × 80 mm × 35 mm) |
