Overview
The Inventory Master LoRa WAN gateway is a product featuring high reliability, high performance, and cost-effective. It is an 8-channel LoRa WAN gateway based on SX 1308 with build-in ESP 8266 WiFi connectivity. With multiple versions and various power outlets available, it satisfies a wide range of applications requiring dynamic coverage. As an IoT gateway designed by The Things Network, it enjoys all the superior functions TTN provides to its customers. And of course, this gateway is able to connect with the secure and collaborative Internet of Things Network which is built that spans across many countries around the globe to provide coverage to millions of people. The tool which a lot of people apply in their community is TTN Mapper. Therefore, you can use this gateway to become one of the contributors of this network by loading onto The Network Console, or enjoy the public community network built up by the other TTN gateways
Features
- Easy installment withback-haul over 802.11 b,g,n
- Globally use
- Advanced Software, support the state-of-the-art
- Basic Station Protocol
- Great reliability
- Compact design for carrying
- Can be powered up via multiple power options
- Built-in omnidirectional antenna for domestic use
- Powerful capability 8 channel LoRa WAN indoor gateway
Technical Specifications
| Chipset | Semtech SX 1308 |
| Channels | 8 Channels |
| Receive Sensitivity | -140 dBm or -135 dBm (EU, US) |
| Transmit Power | Upto +27 dBM |
| LoRaWAN® Spec Version | V.1.0.3 |
| Packet Forwarder | Basic station protocol |
| SoC | ESP 9266 |
| Mode | 802.11 bgn, Client Mode |
| Tx Power | +20 dBm |
| Frequency Bands | 2.4 GHz |
| USB Port | USB Type-C (900 mA) |
| Security | WPA or WPA2 |
| Interfaces | LED indicators |
| Antenna Type | Integrated |
| Frequency Band | EU 868 |
| Operating Temperature | 32 °F to 104 °F (0 ℃ to 40℃) |
| Dimensions | 3.5 in x 3.1 in x 1.6 in (90 mm x 80 mm x 40 mm) |
