Features
- Integrated meter and valve
- Fully wrapped structure
- Anti-vandalism
- Self-diagnosis function
- Flow sensor failure alarm
- Temperature sensor failure alarm
Technical Specifications
| Communication | LoRaWAN or 4G |
| Common Flow | 141 ft³ per h (4.0 m³ per h) |
| Turndown Ratio | 125, 160, 200, 250, 400, 500 |
| Cumulative Volume Resolution | 35 ft³ (0.0001 m³) (user mode), 0.033 fl oz (0.001 L) (test mode) |
| Current Flow Resolution | 0.035 ft³ per h (0.001 m³ per h) (user mode), 0.035 ft³ per h (0.001 m³ per h) (test mode) |
| Battery Life | > (6 + 1) years |
| LCD Screen Digits | 9 bits |
| Temperature Level | T30, T50 |
| Pressure Level | MAP 16 |
| Pressure Loss Level | Δ p 25 |
| Environmental Level | Level 0 |
| Protection Level | IP 68 |
| Accuracy Level | Level 2 |
| Electromagnetic Environment Level | E 1, E 2 |
| Installation Method | Horizontal or vertical |
| Upstream or Downstream Flow Field Sensitivity Level | U 5 or D 3 |
| Flow Sensor | Centre frequency: 1 MHz |
| Flow Pipe Section | Copper |
| Battery | 3.6 V, 9000 mAh |
| Weight | 39.1 oz (1.11 kg) |
| Dimensions | 7.68 in x 3.8 in x 4.25 in (195 mm x 96 mm x 108 mm) |
