Technical Specifications
| Chipset | SX1276 |
| Application | Positioning and Navigation |
| Type | BLE Module |
| Function | IOT System |
| Bluetooth Protocol | Bluetooth 5.0 |
| LoRaWAN Protocol | LoRaWAN 1.0.2B |
| LoRaWAN Band | US915, AU915, EU868, EU433, AS920 to AS923, AS923 to AS925, RU864, ID920, KR920, IN865, KZ865, CLAA, CN470, CN470-Ali |
| LoRa Maximum RF Power | 20 dBm |
| LoRa Sensitivity | -139 dBm @SF12, BW 125 kHz, 434 MHz or 470 MHz -137 dBm @SF12, BW 125 kHz, 868 MHz or 915 MHz |
| Access Quantity | >500 in one LoRa gateway |
| High TX Power Option | Max. 30 dBm and -150 dBm receiving sensitivity |
| Battery | Li-ion rechargeable battery 5300 mAh |
| Data Rate | 300 bps to 30K bps |
| Beacon Access Quantity | 100 beacon messages can be received within 1 s, Maximum of 15 beacon messages at one single LoRa communication |
| Certification | CE, FCC, RCM, BQB |
| Solar Panel | 3 W |
| Peak Current | Max. 140 mA in transmit mode |
| Ingress Protection | IP66 |
| Positioning Precision | 9.84 ft (3 m) |
| Encryption | AES128, X509 |
| Standby Time | 2552 days. Bluetooth receiving windows: 3 s Positioning interval: 5 min (300 s) Average data size: around 12 beacons (5.5 bytes per beacon, 800 ms beacon advestise interval) Use commands to change the period of position report to save power |
| Battery | 5300 mAh |
| Battery Life | Adjustable Position Report Interval: 5s x n (1 to 65536) Heartbeat Report Interval: 30s x n (1 to 65536) Switch: Mechanical Customized data filter and data report: Support FOTA over Bluetooth: Support Max. Beacons Supported: 105, maximum of 15 beacon messages at one single LoRa communication @SF9 |
| Operating Temperature | -40 °F to 185 °F (-40 °C to 85 °C) |
| Dimension | 6.29 in × 6.29 in × 2.16 in (16 cm × 16 cm × 5.5 cm) |
| Weight | 5.29 oz (150 g) |
