Features
- LoRaWAN Class A protocol
- AT Commands to change parameters
- Remote configure parameters via LoRaWAN Downlink
- Built-in Temperature & Humidity sensor
- Tri-color LED to indicate status
- Data log Feature
Technical Specifications
| Technology | LoRaWAN Class A Protocol |
| Power Supply | Built-in 2400 mAh Li-SOCL2 Battery |
| Battery Life | Up to 10 Years |
| Built-In Temperature Sensor | Resolution: 32.02 °F (0.01 °C) Accuracy Tolerance: Typical ± 32.54 °F (0.3 °C) Long Term Drift: < 32.04 °F (0.02 °C) per yr |
| Built-In Humidity | Resolution: 0.04 % RH Accuracy Tolerance: Typ ± 3 % RH Long Term Drift: < 32.04 °F (0.02 °C) per yr |
| External Temperature Sensor | Resolution: 32.11 °F (0.0625 °C) ± 0.5 °C accuracy from 14 °F to 185 °F (-10 °C to 85 °C) ± 2 °C accuracy from -55 °F to 257 °F (-55 °C to 125 °C) |
| Connectivity Mode | OTAA or ABP |
| Frequency | CN 470, EU 433, KR 920, US 915, EU 868, AS 923, AU 915, IN 865 |
| Operating Range | Built-in temperature: -40 °F to 257 °F (-40 °C to 125 °C) Built-in humidity: 0 % to 96 % RH External temperature: -55 °F to 257 °F (-55 °C to 125 °C) |
