Features
- Long Battery Life
- Multiple Sensor Support
- Wide Humidity Range
- Long Communication Range
Technical Specifications
| LoRa Protocol | LoRaWAN 1.0.2 B |
| LoRa Frequency | US 915 MHz, AU 915 MHz, EU 868 MHz, EU 433 MHz, AS 920 MHz to 923 MHz, AS 923 Mhz to 925 MHz, RU 864 MHz, ID 920 MHz, KR 920 MHz, IN 865 MHz, KZ 865 MHz, CLAA, CN 470 MHz |
| Sensitivity | SF = 7 ≤ – 126 dBm, SF = 10 ≤ – 136 dBm, SF = 12 ≤ – 142 dBm |
| Operating Current | 7 μA at sleep mode, max. 138 mA at 20 dBm |
| Accuracy | ± 33.8 °F (1 ℃) |
| Standby Time | 5 years at 77 °F (25 ℃) 17 dBm 5 min interval |
| Operating Humidity | 5 % RH to 95 % RH |
| On or Off | Support |
| Sensor | PT100 platinum RTD, maximum 4 sensors supported, cable length is optional |
| Antenna | External |
| Battery | Non-chargeable lithium battery 19 Ah |
| Communication Distance | > 1.2 mi (2 km) |
| Temperature Range | – 328 °F to 392 °F (- 200 °C to 200 °C) |
| Operating Temperature | – 40 °F to 185 °F (- 40 °C to 85 °C) |
| Storage Temperature | – 67 °F to 185 °F (- 55 °C to 85 °C) |
| Dimension | Aluminium, 3.0 in x 1.8 in x 4.3 in (76 mm x 46 mm x 110 mm) |
