Technical Specifications
| BIOS | AMI EFI BIOS |
| Memory | 1 x SO-DIMM DDR5 4800MHz, compatible with 5200 MHz or 5600MHz |
| Storage | 1 x M.2NVMe(PCle3.0 X1 signal) 1 x SATA3.0 1 x TF |
| Display Chip | Integrated UHD Graphics Card |
| Display Port | 1 x HDMI 2.0, support 4K@60Hz 1 x DP1.2, support 4K@60Hz 1 x Type-C, support 4K@60Hz |
| Network Cards | 4 x i226-V 2.5G NICs |
| USB TDP | 1 x USB3.0 5 x USB2.0 Base: 6W Turbo: 15W |
| Expansion Pins | 1 x TPM PIN 1 x FPANEL PIN 1 x GPIO PIN 1 x COM PIN |
| Expansion Ports | PCI-E x8 socket (x4 signal) can be plugged into Intel 82599ES dual 10G optical Inteli210 or i211 or i226-V four network ports | 4x1signal M.2 adapter board |
| Other Functions | Power-on boot Scheduled boot Wake-up on LAN PXE boot Watchdog |
| Power Supply | DC12V or 6A or 10A 5.5 x 2.5 interface |
| O or S Supported | Win10, Win server2019 or 2022, Centos, Ubuntu, Exsi, pfSense, Esxi, Debian |
| Working Temperature | -0 to 50℃ Commercial HDD; -20℃ to 50℃ (Industrial SSD); Surface Air flow Commercial HDD: 32°F to 122°F Industrial SSD: -4°F to 122°F |
| Size | 5.20 in x 6.10 in x 2.36 in (132 mm x 155 mm x 60 mm) |
| Weight | (1.75KG) 3.86lbs Net Weight(1.4KG) 3.09lbs |
