Features
- Compact design
- Accurate testing
- Easy operation
- Reliable performance
Technical Specifications
| Fiber Type | SM |
| Connector Type | SC/FC/ST |
| Wavelengths | 1310 nm/1550 nm |
| Dynamic Range | 24/22 dB |
| VFL Output power | ≥10mW |
| Certification | CE RoHS FCC |
| Language | Multi-language |
| OED/ODM | Support |
| Red Light Source | 10 mW, CW/2Hz |
| Data Interface | 2 USB ports (type A x 1, Micro USB x 1), SD card |
| Monitor | 4.3 in TFT-LCD (standard capacitive touch screen) |
| Battery | 3.7 V/5200 mAh |
| Optical Power Meter | Type A: -10 dBm to –70 dBm, Type B: +26 dBm to –50 dBm |
| Network Cable Test Terminal | Support network cable sequence test |
| Distance Range | Up 62 mi (Up 100 km) |
| Sampling Resolution | 0.65 ft minimum (0.2 m minimum) |
| Sampling Point | 64,000 points |
| Linearity | =0.05 dB/dB |
| Loss Threshold | 0.01 dB |
| Loss Resolution | 0.001 dB |
| Range Resolution | 0.03 ft (0.01 m) |
| Distance Accuracy | +(1.64 ft + test distance x 3 x 10^-5+sampling resolution) (excluding refractive index error) |
| Humidity | =95 % (no condensation) |
| Working Temperature | 14 °F to 131 °F (-10 °C to 55 °C) |
| Storage Temperature | -4 °F to 176 °F (-20 °C to 80 °C) |
| Dimension | 6.9 in x 4.1 in x 1.8 in (17.5 cm x 10.5 cm x 4.5 cm) |
| Weight | 1.2 lb. (including battery) (0.56 kg (including battery)) |
