Features
- Multi-touch screen display
- Dual wavelength support
- Real-time monitoring tools
- Dynamic range testing
Technical Specifications
| Specification | Details |
| Use | FTTH |
| Network | None |
| Product Name | OTDR |
| Battery | 7.4V/4.6Ah Rechargeable lithium-ion batteries |
| GPS Function | Displays longitude and latitude position outdoors |
| VIP Function | Displays surface of connector via video inspection probe |
| iOLA Function | Multi-pulse test using short, medium, and long pulses |
| LCD | 7-in (17.78 cm) color LCD, Multi-touch screen |
| Event Dead Zone | 1 m (3.28 ft) |
| Attenuation Dead Zone | 5 m (16.4 ft) |
| Min.Distance Resolution | 0.1 m (3.94 in) |
| Loss Resolution(dB) | 0.001 |
| VFL Function | 10 mW |
| OPM | 850/980/1270/1300/1310/1490/1550/1577/1625/1650 nm |
| Storage | >10,000 results |
| Connector | FC/PC (1310 nm/1550 nm) interchangeable adapter or customize |
| Pulse Width | 5 μs to 20 μs |
| Distance Uncertainty | ± (0.8 + 0.005% x Testing Distance + Resolution) |
| OPM Function | +26 to -50 dBm, 850/980/1270/1300/1310/1490/1550/1577/1625/1650 nm, FC or SC adapter |
| Storage Format | >10,000 results (SOR or PDF) |
| Storage Temperature | -22 °F to +140 °F (-30 °C to +60 °C), <90% RH |
| Operating Temperature | +14 °F to +122 °F (-10 °C to +50 °C), <90% RH |
| Size | 9.7 in x 6.83 in x 2.76 in (24.65 cm x 17.35 cm x 7 cm) |
| Weight | About 1.55 kg (3.42 lbs.) |
