Technical Specifications
| Display | 10.1-in high-definition display |
| Level Accuracy | ±1 dB |
| Level Resolution | 0.1 dB |
| Maximum Input Safety Power | 26 dBm（9kHz to 6.3GHz） 25 dBm（9kHz to 9 GHz/20 GHz） |
| Third Order Intermodulation Intercept Point | 100 kHz to 3 GHz: ≥+10 dBm3 GHz to 6.3 GHz: ≥+12 dBm |
| Second Harmonic Suppression | <-75 dBC |
| Residual Response | <-90 dBm |
| Reference Level Range | -130 dBm to +30 dBm |
| Standing Wave Ratio | <2.0 |
| Spectral Sweep Speed | 9 kHz to 6.3 GHz：18 GHz/s@25 kHz9 kHz to 9 G/20 G：137 GHz/s@25 kHz |
| Real-Time Spectrum Analysis Bandwidth | Max. 100MHz |
| Demodulation Analysis Support Model | 5G NR、LTE、 |
| Use | FTTH FTTX Field Communication Analyzer |
| Network | 3G, 4g, GSM, Wi-Fi, GPRS, Wireless Lan, Wiegand |
| Phase Noise | ≤-106 dBc/ Hz@10 kHz Offset at1 GHz |
| Level Accuracy | ±1 dB |
| Level Resolution | 0.1 dB |
| Maximum Input Safety Power | 26 dBm (9 kHz to 6.3 GHz) 25 dBm (9 kHz to 9 GHz/20 GHz) |
| Second Harmonic Suppression | <-75 dBC |
| Residual Response | <-90 dBm |
| Reference Level Range | -130 dBm to +30 dBm |
| Demodulation Analysis Support Model | 5G NR, LTE, NB-IoT,WCDMA,GSM,Vector Signal |
| Power Supply | AC100 to 240 V/50 to 60 Hz DC19 V |
| Operating Temperature | 14 ℉ to 122 ℉ (-10 ℃ to 50 ℃) |
| Dimension W x H x D | 12.24 in x 8.11 in x 2.40 in (31.1 cm x 20.6 cm x 6.1 cm) |
| Max Weight | ≤ 5.51 lb. (2.5 Kg) |
