Features
- Voltage 12 V
- 5 V Current 50 mA
- Includes AC buzzer and LED light support
- Supports 125 KHz and 13.56 MHz card interface
- Interface options are Wiegand 26 or Wiegand 34, UART and USB
- Compact size 47 mm x 26 mm x 5 mm (including antenna)
- Industrial-grade, operational from -4 °F to 167 °F
- EM 4100 card reading distance > 3.14 in
- S 50, S 70, FM 1208 card reading distance > 1.96 in
Technical Specifications
| Frequency | 125 KHz and 13.56 MHz |
| Power Supply | 5 V or 12 V |
| Reading Range | 1.97 in to 3.15 in (5 cm to 8 cm) |
| Interface | Wiegand26/34, UART |
| Current | 50 mA |
| Supporting Card | EM 4100 or S 50 or S 70 or FM 1208 |
| Operating Temperature | -4 °F to 167 °F (-20 °C to 75 °C) |
| Dimension | 1.85 in x 1.02 in x 0.19 in (47 mm x 26 mm x 5 mm) |
| Weight | 7.05 oz (199 g) |
