Features
- Long Duration Time
- AMR Ready
- Pipe Supplying
- Application Ready
Technical Specifications
| Pipe Materials | Cast Iron |
| Metrological Class | Class 2 |
| Interface & Communication (Optional) | IrDA, LoRaWAN, Sigfox, NB-IoT,W-MBus, RS485, MBus, Pulse Output |
| Ratio (Q3/Q1) (Optional) | R125, R200, R250, R500 |
| Maximum Admissible Pressure | 1.6 MPa |
| Pressure Loss | △P < 40 kPa |
| Flange Standard (Pptional) | ANSI, GB (DIN) |
| Pressure Stage | PN16 |
| Installation Position | U10 / D5 |
| Protection Class (Optional) | IP65 / IP68 |
| Battery Lifespan (optional) | 3.6 VDC Lithium Battery, 6 / 10 / 16 years Lifetime |
| Data Storage (Optional) | 24/120 Logs, Daily / Weekly / Monthly |
| Electromagnetic Environmental Class | E1 |
| Mechanical Environmental Class | M1 |
| Mechanical Environmental Conditions | B |
| Assembly Orientation | H, V, H/ V |
| Display and Indication | Unit: m3 / Gallon (Optional) LCD: 9-digits |
| Temperature | Medium Range: 32.18 ℉ to 86/122 ℉ (0.1 ℃ to 30/50 ℃) (T30 / T50) Ambient temperature: 41 ℉ to 131 ℉ (5 ℃ to 55 ℃) Storage temperature: -4 ℉ to 140 ℉ (-20 ℃ to 60 ℃) |
