Features
- Comprehensive xDSL compatibility
- Fast copper line testing
- Modem emulation support
- Rechargeable Li-ion battery
Technical Specifications
| Output Power | Available |
| Error Test | CRC, FEC, HEC, NCD, LOS |
| Display DSL Connect Mode | Available |
| Display Channel Bit Map | Available |
| ADSL2+ Standards | ITU G.992.1 (G.dmt), ITU G.992.2 (G.lite), ITU G.994.1 (G.hs), ANSI T1.413 issue #2, ITU G.992.5 (ADSL2+) Annex L |
| ADSL Standards | ITU G.992.1 (G.dmt), ITU G.992.2 (G.lite), ITU G.994.1 (G.hs), ANSI T1.413 Issue #2 |
| Up Channel Rate | ADSL2+: 01.2 Mbps, ADSL: 01 Mbps |
| Down Channel Rate | ADSL2+: 024 Mbps, ADSL: 08 Mbps |
| Up/Down Attenuation | 0 to 63.5 dB |
| Up/Down Noise Margin | 0 to 32 dB |
| DMM Test (DC Voltage) | 0 to 400 V |
| DMM Test (AC Voltage) | 0 to 400 V |
| Loop Resistance | 0 to 20000 Ω |
| Capacitance | 0 to 1000 nF |
| Insulation Resistance | 0 to 50 MΩ |
| Optical Power Meter (Optional) | Measurement range: -70 dBm to +10 dBm or -50 dBm to +26 dBm |
| Wavelength (Optical Power Meter) | 850 nm, 1300 nm, 1310 nm, 1490 nm, 1550 nm, 1625 nm |
| Visual Fault Locator (Optional) | Output power: 10 mW, Wavelength: 650 nm ± 20 nm |
| Tone Tracker (Optional) | Output power: 10 mW, Wavelength: 650 nm ± 20 nm |
| TDR Function (Optional) | Test range: < 1.55 mi (2.5 km), Dead zone: < 3.28 ft (1 m), Resolution rate: 3.28 ft (1 m) |
| LCD | 800 x 480 TFT |
| Power Supply | Internal rechargeable 6600mAh Li-ion battery |
| Battery Duration | 4 to 5 hours |
| Working Temperature | 32 ℉ to 104 ℉ (0 °C to 40 °C) |
| Working Moisture | 5% to 90% |
| Dimensions | 6.69 in x 2.75 in x 2.04 in (17 cm x 7 cm x 5.2 cm) |
| Weight | < 1.32 lb (0.6 kg) |
