Features
- Auto power monitoring
- Bidirectional loss test
- Optical return loss
- Automatic wavelength identification
Technical Specifications
| Spectrum Width | ≤5 nm |
| Emitter Type | FP-LD |
| Output Power | >-4 dBm |
| Power Stability | ±0.05 dB/15min; ±0.10dB/8hr |
| Output Mode | CW, 270Hz, 1KHz, 2KHz |
| Calibrated Wavelength | 850, 1300, 1310, 1490, 1550, 1625 nm |
| Display Unit | W/mW/μW/nW/pW/dBm/dB (REF) |
| Detector Type | Ingas |
| Resolution | 0.01 dB |
| Auto Wavelength Identification | Yes (With Shineway Tech specified Stabilized Laser Source) |
| MOD Identification | 270 Hz, 1 KHz, 2 KHz |
| ORL Range | 0 dB to 60 dB (APC connector) |
| ORL Accuracy | ±0.75 dB @ (0 to 50dB), ±1.5 dB @ (50 to 60dB) |
| ORL Uncertainty | ±0.5 dB@20 dB |
| Connector | FC (interchangeable SC, ST) |
| Data Storage | 1000 records |
| Data Interface | USB |
| Backlight Display | Yes |
| Auto Off | Yes (auto-off after 5 minutes idle) |
| Power Supply | Lithium Battery/ AC Adapter |
| Battery Life | Continuous operation ≥35 hours |
| Operating Temperature | -4 ℉ to 122 ℉ (-20 °C to 50 °C) |
| Storage Temperature | -40 ℉ to 148 ℉ (-40 °C to 70 °C) |
| Relative Humidity | 0% to 95% (non-condensing) |
| Dimensions (H×W×T) | 6.96 in x 3.14 in x 1.73 in (17.7 cm × 8 cm × 4.4 cm) |
| Product Weight | 12.34 oz (350 g) |
