Features
- Large Data Storage
- One Time Slot Monitored
- Error Insertion and Check
- Alarm Insertion and Check
Technical Specifications
| Connector | Standard: 75 ohm unbalanced, high resistance input impedance Optional: 120 ohm balanced |
| Input Sensitivity | 0 dB to 43 dB |
| Circuitry Code | HDB3 |
| Frame Type | Framed N×64 Kbps / Unframed |
| Frame Pattern | PCM30, PCM30CRC, PCM31, PCM31CRC |
| Test Pattern | Random pseudo code: 2^15-1, 2^11-1 Fixed code: 1111, 0000, 1010 |
| Insertion and Check | LOS, LOF, AIS, RA |
| Error Code Insertion | Single, 10E-3, 10E-5, 10E-7 |
| Result Analysis | G.821, G.826, M.2100 |
| Storage | >100,000 results |
| Data Transfer | USB |
| Power Supply | Built-in rechargeable battery |
| Storage Temperature | -4 ℉ to 140 ℉ (-20 °C to +60 °C), <90% RH |
| Operating Temperature | 14 ℉ to 122 ℉ (-10 °C to + 50 °C), <90% RH |
| Size (H × W × D) | 7.67 in x 4.33 in x 2.36 in (19.5 cm × 11 cm × 6 cm) |
| Weight | About 17.63 oz (500 g) |
