Features
- Clear touchscreen display
- Accurate measurement results
- Extended distance range
- Robust and durable design
Technical Specifications
| Display | 5.6 in (14.2 cm) LCD touch screen |
| Linearity | ±0.05 dB/dB |
| Loss Threshold | 0.05 dB |
| Loss Resolution | 0.01 dB |
| Sampling Resolution | 0.125 ft to 8 ft (0.04 m to 2.44 m) |
| Sampling Points | 32,000 |
| Distance Uncertainty | ± (3.28 ft + 5 × 10 × distance + sampling interval) |
| Distance Range | 0.18 mi to 112.5 mi (0.3 km to 180 km) |
| Real-Time Refresh Rate | 0.2 s |
| Measurement Duration | User-defined, 5 s, 10 s, 15 s, 30 s, 1 min, 2 min, 3 min selectable |
| Optical Interface | FC/UPC (PC, APC selectable) |
| Data Interface | USB interface, SD card interface |
| Relative Humidity | 0 % to 95 % non-condensing |
| Power Supply | Lithium battery, 8 hours continuous working duration |
| Wavelength | 650 nm |
| Output Power | ≥ -3 dBm |
| Max Testing Distance | 112.5 mi (180 km) |
| Operating Temperature | 14 °F to 122 °F (-10 °C to 50 °C) |
| Storage Temperature | -40 °F to 158 °F (-40 °C to 70 °C) |
| Dimension | 5.9 in x 9.25 in x 2.6 in (15 cm x 23 cm x 6.6 cm) |
| Weight | 3.3 lbs. (1.5 kg) |
