Features
- Dual Wavelength Operation
- Fiber Link Map
- Compact Portable Design
- Integrated Testing Functions
Technical Specifications
| Dead Zone | Event: 9.8 ft (3 m) / Attenuation: 26.2 ft (8 m) |
| Sampling Resolution | Min 0.16 ft (0.05 m) |
| Sampling Points | Max 128,000 |
| Distance Accuracy | ±(3.28 ft + test distance × 3 × 10⁻⁵ + sampling resolution) (excluding IOR uncertainty) |
| Memory Capacity | 80,000 groups curve |
| Visual Fault Locator (VFL) | 10 mW, CW/2 Hz |
| Display | 5-inch TFT-LCD touch screen |
| Battery | 7.4 V/3300 mAh lithium battery; Continuous work: 6 hours (backlight off); Charge time: 3.5 hours |
| Operating Temperature | 14 °F to 122 °F (-10 °C to 50 °C) |
| Dimensions | 7.7 in × 5.6 in × 1.7 in (19.5 cm × 14.1 cm × 4.4 cm) |
| Weight | 1.98 lbs (0.9 kg) |
