| Emitter Type | Laser |
| Safety Class | Class 1 F D A 21 CFR 1040.10 and 1040.11, IEC |
| 60825 to 1: 2007-03 |
| Fiber Type | Single-mode |
| Available Wavelengths | FS200 to 50: 1510 ±20 nm |
| FS200 to 100: 1310/1550 ±20 nm |
| Wavelength Tolerance | ±20 nm |
| Dynamic Range (SNR=1) b | 32/30 dB @1310/1550 nm |
| Event Dead Zone c | 2.62 ft (0.8 m) |
| Attenuation Dead Zone d | (11.81 ft 3.6 m) |
| Pulse Widths | 3, 5, 10, 20, 30, 50, 100, 200, 300, 500 ns; |
| 1, 2, 3, 10 µs |
| Range Settings | 820 ft to 1.49 mi (250 m to 240 km) |
| Data Points | Up to 2,300,000 / 1.96 in (5 cm) data-spacing |
| Data Spacing | 52.49 ft (16 m) |
| Group Index Of Refraction | 1.4000 to 1.7000 |
| Distance Uncertainty (m) | ± 3.28 ft (1) + 0.005% x distance + data point spacing) |
| Linearity | ±0.05 dB/dB |
| Trace File Format | Telcordia SR-4731 Issue 2 |
| Trace File Storage Medium | 4 GB internal memory (>1000 traces); |
| External USB memory stick |
| Data Transfer to PC | USB cable or Wi-Fi (option) |
| Standard OTDR Modes | SmartAuto, Expert, Real Time |
| Display Modes | LinkMap Summary, LinkMap Events, Trace |
| Real-time Refresh Rate | Up to 4 Hz |
| Live Fiber Protection | No OTDR damage with input power ≤ +3 dBm |
| for wavelength(s) in range 1260 to 1675 nm |
| Live Fiber Detection | Reports live fiber with input signal ≥ to 35 dBm |
| for wavelength(s) in range 1260 to 1675 nm |
| Power | Rechargeable Li-Ion or AC adapter |
| Battery Life | >12 hours, Telcordia test conditions |
| Display | Color touchscreen 4.3 in LCD, 480 x 272, backlit |
| USB Ports | 1 host; 1 micro-USB function |
| Blue Tooth (Optional) | Compatible with Windows PC, Apple iOS, Android |
| Calibrated Wavelengths | 1310, 1490, 1550, 1625, 1650 nm |
| Detector Type | InGaAs, 2 mm diameter |
| Measurement Range | +23 to -50 dBm |
| Tone Detect Range | +3 to -35 dBm |
| Wavelength ID Range | +3 to -35 dBm |
| Accuracy e | ±0.25 dB |
| Resolution | 0.01 dB |
| Measurement Units | dB, dBm or Watts (nW, µW, mW) |
| WiFi (Optional) | IEEE 802.11 / WLAN |
| Operational Temperature | 14 ℉ to 122 ℉ (-10 °C to +50 °C), 0 to 95 % RH (non-condensing) |
| Storage Temperature | -40 ℉ to 158 ℉ (-40 °C to +70 °C), 0 to 95 % RH (non-condensing) |
| Size (In Boot) | 3.38 in x 6.29 in x 1.69 in (8.6 cm x 16 cm x 4.3 cm) |
| Weight | 0.88 lb (0.4 kg) |
