| CPU | Broadcom BCM2711, Quad-core A72 (ARM v8) at 1.5 GHz |
| Memory | 2GB (1GB / 4GB / 8GB optional) LPDDR4 |
| Flash | 8GB (16GB / 32GB optional) eMMC |
| Operating System | Raspbian / ElastOS |
| Interfaces | GbE/D/I/DO/RS232/RS485 |
| Network | 4G LTE, 3G, 2G, NB-IoT, CAT-M1 |
| Wi-Fi | Dual-band 2.4GHz / 5GHz 802.11b / g / n |
| GPS | Supported (optional) |
| LoRaWAN | Supported (optional) |
| DIN-Rail and Wall Mount Support | 1.38 in DIN-Rail (3.5 cm) |
| Isolation and Protection | EMC & ESD Protection, 1.5 kV RMS Ports isolation |
| RTC | Built-in RTC with supercap |
| Data Security | SIM card slot and Console port lock set for data security |
| Firmware | Raspbian / OpenWRT Based Linux OS, Docker, Node-RED, Python available |
| Software Bundling | Pre-compiled software for data acquisition, Modbus, MQTT, etc. |
| Interoperability | Compatible with Azure, AWS, ThingsBoard, etc. |
| Additional Features | Standalone watchdog timer |
| Ethernet | Gigabit Ethernet x 1, (1-WAN or 1-LAN configurable) |
| Cellular | 4G LTE / 3G / 2G / NB-IoT / CAT-M1 |
| Bluetooth | Supported |
| GPS | Cellular Module built-in supported (optional) |
| SIM | 1.8V / 3V; drawer-type Nano card holder x 1 |
| ESD Protection | 15kV |
| Antenna | 4G: inside SMA x 1, Wi-Fi / Bluetooth: inside SMA x 1 |
| Industrial Serial Port | RS-232 signal: TXD, RXD, GND; RS-485 signal: A, B, GND; ESD protection: 15kV |
| I/O | 2-channel digital input DI |
| USB | USB-C x 1 for Power supply and Console; USB 2.0 x 2 for peripherals |
| HDMI | HDMI 2.0 x 1 (Up to 4k at 60 video & audio output) |
| Additional drive | 1 x M.2 socket with 2280 NVME SSD support |
| Power Supply | Wide Range Voltages 9-36V DC / 1A |
| Power Terminal | Unpluggable industrial terminal connection |
| Power Consumption | Less than 10 W (system) |
| RTC (Optional) | Embedded RTC, power supply with a supercapacitor |
| Protection | IP30 |
| Housing | Aluminum Heatsink |
| Installation | DIN-rail, wall mounting |
| Ambient Humidity | 5 % to 85 % (non-condensing) |
| Operating Temperature | -13 °F to 158 °F (-25 °C to 70°C) |
| Storage Temperature | -22 °F to 167 °F (-30 °C to 75 °C) |
| Dimensions (cm) | 4.88 in x 3.00 in x 1.38 in (12.4 cm x 7.6 cm x 3.5 cm) |
