Features
- Enabling multiple backhaul connectivities
- High reliability and global scalability
- Durable enclosure
- Powerful performance for faster data processing
- Ease of installation
- Wide applications
Technical Specifications
| Application | Smart agriculture, city, logistics, utilities |
| Power Supply | 12 V DC, PoE (IEEE 802.3 af), 40 V to 57 V DC |
| LoRaWAN Mode | LoRaWAN™ Specification 1.0.3, Class A/B/C |
| Processor | MT7628, DDR2 RAM 128 MB |
| Wi-Fi Frequency | 2.4 GHz (802.11 b/g/n) |
| Wi-Fi RX Sensitivity | -95 dBm (min) |
| Wi-Fi TX Power | 20 dBm (max) |
| Wi-Fi Channels | 1 to 13 |
| LoRa Channels | 8 or 16 |
| LoRa RX Sensitivity | -139 dBm @ 125 kHz / SF12 |
| LoRa TX Power | 27 dBm (max) |
| LoRa Frequencies | EU433, CN470, EU868, US915, AS923, AU915, IN865, KR920, RU864 |
| Cellular Modules | EC25-E (EU/SK/IN), EC25-AFXD (NA), EC200M-CN (China) |
| Cellular Bands | Varies by module – LTE FDD/TDD, WCDMA, GSM/EDGE |
| Ethernet | RJ45 (10M or 100M) |
| Console Interface | USB Type-C |
| Antenna Interfaces | LoRa, LTE, Wi-Fi, GPS – All N Type Connectors |
| Ingress Protection | IP67 |
| Material | Aluminum |
| Operating Temp | -40 °C to 85 °C (-40 °F to 185 °F) |
| Storage Temp | -40 °C to 85 °C (-40 °F to 185 °F) |
| Humidity | 10% to 90% RH |
| Dimensions | 18.5 cm × 18.5 cm × 4.3 cm (7.28 in × 7.28 in × 1.69 in) |
| Weight | 3 kg (6.61 lb) |
