Features
- Industrial Gateway
- LoRaWAN Compatible
- Supports Class A/B/C
- 8/16 Channel Options
- PoE Power Ready
- 10KV Lightning Proof
Technical Specifications
| LoRaWAN Compatibility | Supports Class A or B or C modes |
| Channel Support | 8 or 16 channels for uplink; 1 to 2 channels for downlink |
| Duplex Mode | Optional half-duplex or full duplex |
| Output Power | Max 25 dBm |
| Power Supply Options | Supports PoE, external DC, internal backup, solar expansion |
| Battery Backup | Supports full load for more than 4 hours |
| Antenna Interface | 4G, Wi-Fi, and LoRa: N to J female connectors |
| Protection | IP67 rated for outdoor use, 10KV lightning protection |
| Frequency Bands | 434MHz, 470MHz, 510MHz, 868MHz, 915MHz |
| Interfaces | USB debugging, 10 or 100M Ethernet, 4G wireless (WCDMA or TD-LTE or GPRS or EDGE) |
| LoRa Sensitivity | -141 dBm @ 300 bps, SF12, BW 125 KHz |
| Max LoRa Output Power | +27 dBm |
| CPU | ARM Cortex-A53 1.2 GHz |
| Working Temperature | -40 °F to 167 °F (-40 °C to 75 °C) |
| Antenna Size | 8.26 in x 7.87 in x 3.34 in (21 cm x 20 cm x 8.5 cm) |
| Weight | 7.40 oz (210 g) |
