Features
- Quad-Core 64-bit Processor: Powerful Performance.
- Semtech SX1302: remarkable ability to handle traffic loads.
- Various Internet Connections: Ethernet, Wi-Fi, or 3G/4G backup.
- Standard LoRaWAN Protocol: flexible network accessing, wide connection.
- IP67 Waterproof: Designed for the outdoors, fearless of wind and rain.
- Embedded Network Server: Connect to Server via TCP/HTTP/MQTT.
- Large Capacities: Up to 2000 end node
Technical Specifications
| Processor | Quad-core 1.5 GHz, 64-bit ARM Cortex-A53 |
| Radio Chip | SX1302 |
| Frequency | AU915 |
| Tx Power | 27 dBm Max |
| Wireless Protocol | LoRaWAN, Wi-Fi, Bluetooth 5.0 |
| Protocol | V1.0 Class A/Class B/Class C and V1.0.2 Class A/Class B/Class C |
| Ports | 1 x 10/100/1000Mbps RJ45 (PoE PD supported), auto MDI/MDIX |
| VPN Tunnel | DMVPN/IPsec/OpenVPN/PPTP/L2TP/GRE |
| Waterproof Rating | IP67 |
| Power Supply | 802.3 af PoE Input, 12 VDC with M12 Connector |
| Working Temperature | -40 °F to 158 °F (-40 °C to 70 °C) |
| Working Current | Typical 3.6 W, Max 4.8 W |
| Power Input | 1 x 802.3 af PoE Input or 12 VDC with M12 Connector |
| Antenna | 2 x Antenna connectors |
| SIM Slot | 1 x Mini-SIM (2FF) |
| Micro SD | 1 x SD card slot |
| Dimensions | 7.87 in x 7.87 in x 2.36 in (20 cm x 20 cm x 6 cm) |
| Weight | 21.16 oz (600 g) |
