Technical Specifications
| Protection Grade | IP67/NEMA-6 Industrial protection grade enclosure (with cable interface) |
| Power Over Ethernet | PoE (802.3af) + Surge protection |
| LoRa Concentrator | Dual LoRa concentrator, can contain up to 16 channels |
| Connectivity | Supports Wi-Fi, LTE, and Ethernet |
| GPS | Yes |
| Power Supply | Supports DC 12V or solar power supply with power monitoring (solar energy kit optional) |
| Antenna | Built-in antenna applied (external antenna if used) |
| Power Off Alarm | Optional |
| Gateway Function | Built-in LoRa server |
| OpenVPN Client | Supported |
| Software | OpenWRT-based user interface |
| Protocol | Based on LoRaWAN 1.0.3 protocol |
| LoRa Frame Filtering | Node whitelist |
| MQTT | v3.1 bridge with TLS encryption |
| Data Handling | Support for buffer in packet mode, no data loss when NS is interrupted |
| Half Duplex | Optional |
| Time Stamp | Optional |
| Type | Customizable |
| System Composition | LoRaWAN module, gateway, application services |
| Accessories | Antenna, power supply, bracket, etc. |
| Features | Low power consumption, low cost, long communication distance |
| Frequency | 433 MHz to 928 MHz |
| Communication Distance | Greater than 9.32 miles (15 km) |
| Communication Support | Wi-Fi, LTE, and Ethernet |
| Waterproofing Grade | IP67, NEMA-6 industrial protection grade housing |
