Technical Specifications
| Description | S5735S-L8P4S-A1 (8*10/100/1000BASE-T ports, 4*GE SFP ports, PoE+, AC power) |
| Chassis Height [U] | 1 U |
| Typical Power Consumption [W] | 28.4 W |
| Typical Heat Dissipation [BTU/Hour] | 96.9 BTU/hour |
| Maximum Power Consumption [W] | Not providing the PoE function: 38.6 W 100% PoE loads: 162.6 W (PoE: 124 W) |
| Maximum Heat Dissipation [BTU/Hour] | Not providing the PoE function: 131.71 100% PoE loads: 554.81 |
| MTBF [Year] | 66.56 year |
| MTTR [Hour] | 2 hours |
| Availability | >0.99999 |
| Noise at Normal Temperature (Acoustic Power) [dB(A)] | 42.2 dB(A) |
| Noise at Normal Temperature (Acoustic Pressure) [dB(A)] | 30.5 dB(A) |
| Number of Card Slots | 0 |
| Number of Power Slots | 0 |
| Number of Fans Modules | 1 |
| Redundant Power Supply | Not supported |
| Long-Term Operating Relative Humidity [RH] | 5% to 95%, noncondensing |
| Long-Term Operating Altitude [m(ft.)] | 0 m to 5000 m (0 ft to 16404 ft.) |
| Storage Altitude [m(ft.)] | 0 m to 5000 m (0 ft to 16404 ft.) |
| Power Supply Mode | AC built-in |
| Rated Input Voltage [V] | AC input: 100 V AC to 240 V AC, 50/60 Hz |
| Input Voltage Range [V] | AC input: 90 V AC to 290 V AC, 45 Hz to 65 Hz |
| Maximum Input Current [A] | 3 A |
| Memory | 512 MB |
| Flash Memory | 512 MB |
| Console Port | RJ45 |
| Eth Management Port | Not supported |
| USB | Not supported |
| RTC | Not supported |
| RPS Input | Not supported |
| Service Port Surge Protection [kV] | Common mode: ±7 kV |
| Power Supply Surge Protection [kV] | ±6 kV in differential mode, ±6 kV in common mode |
| Types of Fans | Built-in |
| Heat Dissipation Mode | Heat dissipation with fan, intelligent fan speed adjustment |
| Airflow Direction | Air intake from left and front, air exhaustion from right |
| PoE | Supported |
| Products Status | Stock |
| Ports | ≤ 8 |
| Function | LACP, POE, QoS, SNMP, VLAN Support |
| DRAM Memory | 512 MB |
| Flash Memory | 512 MB |
| Relative Humidity | 5% to 95%, noncondensing |
| Weight Without Packaging [kg(lb.)] | (2.25 kg) 4.96 lb. |
| Weight With Packaging [kg(lb.)] | (3.17 kg) 7 lb. |
| Dimensions Without Packaging (H x W x D) [mm(in.)] | Basic dimensions (excluding the parts protruding from the body): 4.36 cm x 30.0 cm x 22.0 cm (1.72 in. x 11.8 in. x 8.7 in.) Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 4.36 cm x 30.0 cm x 22.70 cm (1.72 in. x 11.8 in. x 8.94 in.) |
| Dimensions With Packaging (H x W x D) [mm(in.)] | 11.0 cm x 43.50 cm x 36.0 cm (4.33 in. x 17.13 in. x 14.17 in.) |
| Long-Term Operating Temperature [°C(°F)] | -5 °C to +50 °C (23 °F to 122 °F) (0 m to 1800 m altitude, non-industrial optical modules) -5 °C to +55 °C (23°F to 131 °F) (0 m to 1800 m ) 0 feet to 5,905.51 feet altitude, industrial optical modules with transmission distances less than or equal to (10 km) 6.21 mi |
| Short-Term Operating Temperature [°C(°F)] | Not supported |
| Restriction on the Operating Temperature Variation Rate [°C(°F)] | When the altitude is 1800 m to 5000 m (5906 ft to 16404 ft.), the highest operating temperature reduces by 1 °C (1.8 °F) every time the altitude increases by 220 m (722 ft.). The switch cannot be started when the ambient temperature is lower than 0°C (32°F). The operating temperature ranges from -5°C to +45°C (23°F to 113°F) when optical modules with transmission distances greater than or equal to 43.5 mi (70 km) are used. |
| Storage Temperature [°C(°F)] | (-40 °C to +70 °C) -40 °F to +158 °F |
