Features
- Support single instrument polarity and loss testing at the same time
- Support 24-core and 12-core testing
- 6 -inch LCD touch screen
- Support customizable pass or not in threshold
- Any of two instruments can remote different systems in pair
- Support USB port MPO connector end face inspector function (optional)
Technical Specifications
| OLS Wavelength | 1550 nm (optional) |
| OPM (Optical Power Meter) | 850 nm /1300 nm /1310 nm /1550 nm |
| Port | MPO male connector |
| Display Size | 5.6 in TFT color screen |
| VFL (Visual Fault Locator) | 650 nm |
| Output Power | 10 mW |
| Automatic Shutdown Time | User-defined optional |
| Output Power (Optical) | ≥ -5 dBm |
| Spectral Width (FWHM) | ≤ 5 nm |
| Frequency | CW / 270Hz / 1KHz / 2KHz |
| Power Stability | ≤ ±0.1 |
| Detector Type | Ingas |
| Wavelength Range | 800 nm to 1700 nm |
| Measuring Range | +3 dBm to –50 dBm |
| Power Measurement Linearity | ±0.1 dB |
| Power Measurement Uncertainty | ±0.25 dB |
| Power Unit | dBm / dB / xW |
| Resolution Ratio | 0.01dB |
| Polarity Detection | A, B, C & User-Defined |
| Record Storage | Applied |
| Wavelength Test Range | 800 nm to 1700 nm |
| Power Measurement Uncertainty (Wavelength) | ≤ 0.25 dB |
| Power Supply | 7.4 V 4000mAh Lithium Battery / Micro USB |
| Low Battery Warning | Icon Flashing |
| Communication Interface | Micro USB |
| Operating Temperature | 14 °F to 140 °F (-10 ℃ to +60 ℃) |
| Storage Temperature | -13 °F to 158 °F (-25 ℃ to +70 ℃) |
| Dimension | 10.24 in x 6.10 in x 2.87 in (26 cm x 15.5 cm x 7.3 cm) |
| Weight | 44.18 oz (1250 g) |
