Features
- Adjustable Impulse Voltage Range
- High Precision Voltage Accuracy
- Advanced Safety Protection Features
- Compact And Lightweight Build
- Customizable Power Output Options
Technical Specifications
| Impulse Voltage | 0 kV to 35 kV (default 0 kV to 32 kV) |
| High Pressure Partial Pressure | Voltage Accuracy: ± 1.5 |
| External Capacitance | 1 to 2 μF / 4 μF / 8 μF / 16 μF |
| Impact Time | 1 to 8 seconds |
| Output Voltage Polarity | Negative Polarity |
| Impact Power | 400 W (customizable) |
| Discharge Power | 0 J to 2450 J (default 0 to 1568J) |
| Over-Temperature Protection | 185 °F (85 °C) |
| Overcurrent Protection | 16 A (more than 3 seconds) |
| Working Power Source | AC 220 V ±10% 50Hz ±2Hz (60Hz customizable) |
| Environment Temperature | -4 °F to 122 °F (-20 °C to 50 °C) |
| Volume | 17.91 in x 14.17 in x 14.17 in (45.5 cm x 36 cm x 36 cm) |
| Weight | No more than 55.12 lbs (25 kg) |
