Technical Specifications
| Frequency Range | 9 kHz to 6.3 GHz |
| Frequency Accuracy | ± 0.01 ppm |
| Level Accuracy | ± 1.5 dB |
| Level Resolution | 0.1 dB |
| Power Supply | AC 100 V to 240 V or 50 Hz to 60 Hz DC 12 V |
| Ambient Temperature | 32 ⁰F to 104 ⁰F (0 °C to 40 °C) |
| Wavelength Accuracy | ± 0.5 nm |
| Wavelength Data Output Interval | 1 nm |
| Screen Type | 5 in (12.7 cm) HD IPS capacitive touch screen |
| Maximum Input Safe Power | 25.7 dBm |
| Third Order Intermodulation Interception Point | +12 dBm, typical value |
| Second Harmonic Suppression | -75 dBc |
| Reference Level Range | -130 dBm to +30 dBm |
| Spectrum Scanning Speed | 9 kHz to 6.3 GHz: 18GHz/s at 25 kHz9 kHz to 9 G or 20 G: 137GHz/s at 25 kHz |
| Real Time Spectrum Analysis Bandwidth | Maximum 100 MHz |
| Demodulation Analysis Support Mode | 5G NR, LTE, NB-IoT, WCDMA, GSM, Vector signal |
| Dimension | 11.61 in x 8.86 in x 1.97 in (295 mm x 225 mm x 50mm) |
| Weight | 5.07 lb. (2.3 kg) |
