Key Features
- Frequency Supports various RFID frequencies
- Protocol Conforms to ISO 14443 A standard
- Read Range Detection range of 1.97 in to 3.94 in (5 cm to 10cm)
- Power / Current USB-powered with 100 mA limit
- LED Indicator Dual-colour (Red/Green) status lights
- Beeper Audible alert feature included
- Operating Temperature Range from 14 °F to 158 °F (-10°C to +70°C)
- Operating Humidity Suitable range for environment
- Colour Device colour is black
- Material Constructed from ABS+PC with texture
- Dimension (LWH)mm Physical size specifications
- Weight Device mass is 4.23 oz (120 g)
- 125 KHz Proximity & 13.56 MHz Mifare Card Reader / Writer
- Read Range: Up to 10 cm (125KHz), 5 cm (13.56MHz)
- Read card number only (CR10E/CR10M)
- Read card number & write card number (CR10MW)
- USB interface
- Power by USB
- LED indicator and buzzer feedback
- Avoid manual input mistake
- No need driver, compatible with Windows OS
Technical Specifications
| Read Range | up to 3.937in (10cm), Up to 1.969in (5cm) |
| Frequency | 125 KHz or 13.56 MHz |
| Protocol | ISO 14443 A |
| Power or Current | USB 5V DC or Max.100mA |
| LED Indicator | 2 Colour LED Indicators (Red and Green) |
| Beeper | Yes |
| Operating Temperature | 14 °F to 158 °F (-10 ℃ to +70 ℃) |
| Operating Humidity | 10% to 90% relative humidity non-condensing |
| Colour | Black |
| Material | ABS+PC with texture |
| Dimension (L x W x H) mm | 5.51 in × 3.94 in × 1.18 in (140 mm x 100 mm x 30 mm) |
| Weight | 4.24 oz (120 g) |
