Features
- Working Frequency 125 KHz
- Power Supply DC 9 V to 18 V
- Current 60 mA to 80 mA
- Rated Power ≤ 1 W
- Read Range 09 ft to 0.16 ft (3 cm to 5 cm)
- Card Capacity 2000
- Temperature < 60 degree
- Humidity 10 % RH to 95 % RH
- Size 38 in x 1.33 in X 0.47 in (86 mm X 34 mm X 12 mm)
- Outdoor Button 1
- Sensor Input 1
- Electric Lock Output 1
- With manage card to add or delete user card
- With IR remote switch to add or delete user card (option)
- Application Field building intercom, Lift
Technical Specifications
| Frequency | 125 KHz |
| Protocol | ISO 14443 A |
| Rated Power | ≤ 1 W |
| Read Range | 0.098 ft to 0.164 ft (3 cm to 5 cm) |
| Power Supply | DC 9 V to 18 V |
| Current | 60 mA to 80 mA |
| Humidity | 10 % to 95 % RH |
| Card Capacity | 2000 |
| Working Temperature | <60 degree |
| Outdoor Button | 1 |
| Sensor Input | 1 |
| Electric Lock Output | 1 |
| Range Of Power Supply | +4.6 V to +5.4 V |
| Encoding | Manchester 64-bit, modulus 64 |
| Reading Distance | 0.262 ft to 0.328 ft (8 cm to 10 cm) |
| Size | 3.38 in x 1.33 in X 0.47 in (86 mm X 34 mm X 12 mm) |
