Features
- Work voltage DC 5 V
- Work current 40 mA
- Read frequency 125 KHz
- Communication Interface Wiegand or UART or TTL
- Read distance about 26 ft (8 cm) for EM 4100 Card
- Read distance 16 ft (5 cm) for S 50 or S 70 or Desfire and FM 1208
- Work Temperature -4 °F to 185 °F
- Work Humidity 0 % RH to 95 % RH
Technical Specifications
| Frequency | 125 KHz |
| Protocol | ISO 14443A |
| Interface | USB TTL 232 WG 26 or 34 |
| Read Range | 0 in to 3.93 in (0 mm to 100 mm) |
| Distance Of Transmission | WG 26 or 34>=100 M |
| Work Current | 40 mA |
| Working Voltage | DC 5 V |
| Communication Interface | Wiegand UART TTL |
| Read Range | 0 inches to 3.93 in (0 mm to 100 mm) |
| Read Distance | 0.26 ft (8 cm) for EM 4100 Card |
| Read Distance | 0.16 ft (5 cm) for S 50 or S 70 or Desfire and FM 1208 Card |
| Extend Port I Or O Port | 3 pcs IO Port Optional BUZ and LED |
| Humidity | 0 % RH to 95 % RH |
| Storage Temperature | -4 °F to 185 °F (-20 °C to 85 °C) |
| Size | 1.49 in X 0.70 in X 0.03 in (38 mm X 18 mm 0.8 mm) |
| Weight | 0.52 oz (15 g) |
