Technical Specifications
| Certifications | FCC, CE, RoHS, SRRC |
| Frequency Range | 840 MHz to 960 MHz, adjustable |
| Protocol | EPC C1G2, ISO18000-6B/C |
| Frequency Band | GB: 920 MHz to 925 MHz, 840 MHz to 845 MHz; FCC: 902 MHz to 928 MHz |
| Optional Frequency Band | ETSI: 865 MHz to 868 MHz; JP: 916.8 MHz to 920.4 MHz; TW: 922.25 MHz to 927.75MHz |
| Communication Protocol | COM |
| Reading Distance | 0 cm to 30 cm, adjustable |
| Antenna Gain | OdBi |
| Working Mode | Fixed frequency / frequency hopping optional |
| RF Output Power (Port) | 33 dBm ±1 dBm (MAX) |
| Recognizing Speed | >400 times per s |
| Communication | COM port or HID |
| RS232 | Baud rate support: 9600, 19200, 115200 (default), 460800 optional |
| Material | ABS |
| Power Supply | USB power supply |
| Power Consumption | 15W (output power 33 dBm) |
| Working Humidity | < 95 % at +77 °F (+25 °C) |
| Operating Temperature | -4 °F to +140 °F (-20 °C to +60 °C) |
| Storage Temperature | -40 °F to +185 °F (-40 °C to +85 °C) |
| Dimensions | 14.17 in x 12.60 in x 0.75 in (36 cm x 32 cm x 1.9 cm) |
| Net Weight | 2.2 lb (1 kg) |
