Features
- Triaxial acceleration and speed monitoring
- Frequency response range: 5Hz to 2K
- Equipment surface temperature monitoring
- Replaceable high-capacity lithium sub battery, working for three years
- IP68 waterproof and dustproof protection grade
- Super power design, anti-data loss design
- Inside antenna, small size
- Temporary acquisition of waveform, spectrum and hardware diagnosis by Bluetooth
- Lora and Bluetooth ble5.0 both wireless technology
- Long distance communication 2.5km
- Adopt lorawan international standard
- Protocol and has wide adaptability
- Sensor configuration via Bluetooth, easy to operate
- The acquisition of speed and displacement
- Network disconnection cache monitoring and automatic retransmission
- Intelligent diagnosis algorithm
Technical Specifications
| Measurement Range (Temperature) | -22 °F to 1652 °F (-30 °C to 900 °C) |
| Temperature Accuracy | ± 1°C |
| Acceleration Frequency Range | 5 Hz to 2 kHz |
| Amplitude Range (Acceleration) | ± 16 g peak |
| Accuracy (Acceleration) | ± 5% (160 Hz) Z / X / Y axis |
| Communication Technology | LoRaWAN, bluetooth 5.0 |
| LoRaWAN Frequency Range | 470 MHz to 510 MHz |
| Wireless Range (LoRaWAN) | 1.55 mi (2.5 km) |
| Wireless Range (Bluetooth) | 2.4 GHz ISM band |
| Battery Type | Replaceable C 3.6V lithium sub battery |
| Battery Life | 3 years |
| IP Protection | IP68 waterproof and dustproof |
| Explosion Proof Rating | ExiaIICT4 Zone 0 IIC gas environment |
| Material | 304 stainless steel, reinforced PC |
| Fixing Hole Size | M6 x 1 mm x 0.28 in (7 mm) |
| Mechanical Resistance | 1 meter drop resistance onto concrete |
| Output Type | Digital signal |
| Amplifier Type | IDT |
| Voltage Supply | 5V |
| Current Supply | 0.3 mA |
| Current Supply (Max) | 0.5 mA |
| Mounting Type | DIP |
| Number of Axes | 3 axes |
| Sensing Unit | MEMS |
| Data Acquisition Interval | 20 minute index |
| Output Mode | Total value, effective value |
| Measuring Range (Temperature) | -40 °F to 248 °F (-40 °C to 120 °C) |
| Bluetooth Frequency Range | 2.4 GHz ISM band |
| Bluetooth Power | 2 dBm |
| LORA Frequency Range | 470 MHz to 510 MHz |
| Working Temperature | -40 °F to 158 °F (-40 °C to 70 °C) |
| Corrosion Resistance | Stainless steel body, solution resistant PC |
| Explosion Proof Safety | ExiaIICT4 Zone 0 IIC gas environment |
| Security | Micro power short range radio equipment |
| Operating Temperature Range | -40 °F to 158 °F (-40 °C to 70 °C) |
| Dimensions (Height x Diameter) | 3.35 in x 1.69 in (8.5 cm x 4.3 cm) |
| Weight | 8.05 oz (228 g) |
