Technical Specifications
| Private Mold | No |
| Product Status | Stock |
| Ports | 8 |
| Condition | New |
| Ethernet Ports | 8 x M12 Ports |
| Power | DC: 12 V to 52 V, PoE: 48 V to 57 V |
| Packet Forwarding Rate | 11.9 Mpps |
| MAC Table | 4 K |
| Power Port | M12 A-coded 5-pin female connector |
| Power Indicator | PWR, Link/ACT, PoE |
| Installation Method | Wall-mounted, front plug-in outlet |
| Electrical Ports | 8 x M12 X-coded, 8-pin female connector |
| Power Port | M12 A-coded 5-pin female connector |
| Indicators | PWR, Link/ACT, PoE |
| Switching Capacity | 16 Gbps |
| Packet Forwarding Rate | 11.9 Mpps |
| Cache | 2 Mb |
| MAC Table | 4 K |
| PoE Extension | 8 x PoE/PoE+ |
| Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x |
| Working Mode | Full-duplex, half-duplex auto-negotiation, MDI/MDI-X adaptation |
| Working Humidity | 10 % to 90 % RH (non-condensing) |
| Storage Humidity | 5 % to 95 % RH (non-condensing) |
| Heat Dissipation Method | Natural cooling (fanless) |
| Working Temperature | -40 °F to 167 °F (-40 °C to 75 °C) |
| Storage Temperature | -40 °F to 185 °F (-40 °C to 85°C) |
| Power Supply | DC: 12 V to 52 V; PoE: 48 V to 57 V |
| Size | 6.69 in × 5.20 in × 1.62 in (17 cm × 13.2 cm × 4.12 cm) |
