Features
- Open-Source Embedded Linux system
- Managed by Web GUI, SSH via LAN or WiFi
- Support Semtech UDP packet forwarder
- Support LoRaWAN Station Connection
- Support MQTTS
- Cellular Failover connection(option)
- Direct Communication to LoRaWAN ABP Node
- LoRaWAN packet filtering
- Far seeing LED indicator
- Built-in GPS module for location & timing
- External fiber glass antenna
- Auto-Provision
- Remote Monitoring
- 3af PoE
- IP65
- Lighting Protection
- Power Consumption:12v ,300-500mA
- Operating Temperature：-20~85°C
- Applications:
- Smart Buildings & Home Automation
- Logistics and Supply Chain Management
- Smart Metering
- Smart Agriculture
- Smart Cities
- Smart Factory
Technical Specifications
| Chipset | SX1302 |
| CW Interferer Rejection | 70 dB at 1 MHz offset |
| Negative SNR Operation | Able to operate with negative SNR, CCR up to 9dB |
| Demodulators | Emulates 49 x LoRa demodulators and 1 x (G)FSK demodulator |
| Radio Front-End | Dual digital TX & RX interfaces |
| Parallel Demodulation Paths | 10 programmable paths |
| Data Rate Adaptation | Dynamic data-rate (DDR) adaptation |
| Antenna Operation | True antenna diversity or simultaneous dual-band operation |
| Interface | 10M/100M RJ45 Port x 1 |
| WiFi Support | 802.11 b/g/n |
| LoRaWAN Wireless | Yes |
| Power Input | 12 ~ 24 V DC, 2 A |
| PoE Port | IEEE 802.3 af compliant (DC 37 ~ 57 V) |
| USB Connector | USB 2.0 host x 1 |
| Mini-PCI E Connector | x 1 |
| Chipset | SX1302 + 2 x SX1250 |
