Features
- Support Single Point Control
- Ultra-High-Power Density
- Dual-Stage Architecture
- Built-in Active PFC
- Isolated Dimming
- Lightning Protection
Technical Specifications
| Type | Remote control |
| Max. Load Power | 80 W or 120 W or 150 W or 200 W |
| No-Load Maximum Output Voltage | DC 55 V Max (at no load), DC 27 V to 48 V |
| Rated Current | 4.17 A |
| Rated Output Voltage | 27 V Min, 48 V Max (Po = Vo x lo =150 W full load) |
| Low Frequency Ripple Current (Below 120 Hz) | < 5 % |
| Input Power | 150 W, at 77 °F (25 °C) AC 120 V DC 260 V |
| Input Current | 1.2 Arms Max |
| Input Voltage Range | Rated: AC 100 V to 277 V Limit: AC 90 V to 305 V (refer to derating curve) |
| Frequency Range | 47 Hz to 63 Hz |
| Protection Rating | IP67 |
| Communication Mode | Support 4G cat.1, 2.4G mesh, LoRaWAN, NB-IoT and other communication modes, and supports dual-mode communication |
| Operating Humidity | 10 % RH to 95 % RH, non-condensing |
| Storage Temperature | – 40 °F to 185 °F (- 40 °C to 85 °C) |
| Working Shell Temperature | – 40 °F to 194 °F (- 40 °C to 90 °C) |
| Weight | 26.5 oz (0.75 kg) |
| Dimensions | 9.17 in x 2.92 in x 1.56 in (233 mm x 74.2 mm x 39.7 mm) |
