Technical Specifications
| Type | Ultrasonic meters or Ultrasonic flow meters or Digital or Differential Pressure Flowmeter or Prepaid water meters or Other |
| Protection Class | IP68 |
| Material | Brass, Copper, Iron |
| Installation | Horizontal |
| Working Pressure | 0.03 MPa to 1 MPa |
| Standard | Class B |
| Communication Mode | RS-485 or M-BUS or Pulse or Lorawan or GPRS or GSM or NB-IoT |
| Battery Life | 6 to 8 Years |
| Caliber (DN) | 15 mm, 20 mm, 25 mm |
| Measurement Range (Q3/Q1) | R160 or R250 |
| Overflow Rate (Q4) | 110.4 ft³/h (3.125 m³/h), 176.6 ft³/h (5 m³/h), 278.0 ft³/h (7.875 m³/h) |
| Common Flow Rate (Q3) | 88.3 ft³/h (2.5 m³/h), 141.3 ft³/h (4 m³/h), 221.9 ft³/h (6.3 m³/h) |
| Transitional Flow Rate (Q2) | 0.88 to 2.22 ft³/h (0.025 to 0.063 m³/h) |
| Minimum Flow Rate (Q1) | 0.55 to 1.41 ft³/h (0.0156 to 0.04 m³/h) |
| Maximum Allowable Pressure | 1.6 MPa |
| Flow Section Sensitivity Level | U5 or D3 |
| EMC Level | E1 |
| Protection Degree | IP68 |
| Accuracy Level | Class C |
| LCD Display | 8 digits with prompt |
| Size | 213.39 in x 151.97 in x 55.12 in (542 cm x 386 cm x 140 cm) |
