Features
- Supports the operation of Type A CPU card
- Support WIFI+TCP/IP (POE) communication
- A buzzer and a two-color LED indicator light
- Relay and memory are optional
- The SOCKET interface can be set to either server mode or client mode
- Communication interface can be set to WIFI mode or wireless network card mode or wireless routing mode
- RFID can be set to automatically detect card upload data mode or passive read-write card mode
Technical Specifications
| Frequency | 13.56Mhz or 125Khz |
| Protocol | ISO14443A or 125Khz |
| Standard | ISO or IEC 14443-A, ISO 18092(optional) |
| Interface Options | WIFI+TCP or IP |
| Read And Write | Read UID only or read write |
| Read Distance | 0in to 3.15in (0cm to 8cm) (Depending on label size and antenna technology) |
| Supporting Card | Mifare S50 or S70 or Ultralight, Mifare Pro, NFC, ntag213, ntag216(optional) ect |
| Interface | WIFI+TCP/IP(POE) |
| Other Function | Relay, memory for option |
| Power Supply | External 9V or POE power supply |
| Baud Rate | 9600 to 115200bit or bits (Configurable, default 9600) |
| Operating Temperature | 14°F to 122°F (-10℃ to 50℃) |
| Housing Material | ABS |
| Dimension | 4.6457in x 2.9921in x 0.8661in (118mm x 76mm x 22mm) |
