Features
Hardware features
- Frequency response range: 5Hz to 2K
- Equipment surface temperature monitoring
- Replaceable high-capacity lithium sub battery (working for three years)
- IP68 waterproof and dustproof protection grade
- Super power design with anti-data loss features
- Inside antenna, compact size
- Temporary acquisition of waveform, spectrum, and hardware diagnosis via Bluetooth
- LoRa and Bluetooth BLE 5.0 wireless technologies
- Long-distance communication up to 2.5 km
- Adopts LoRaWAN international standard
- Triaxial acceleration and speed monitoring
- protocol and has wide adaptability
Software features
- Sensor configuration via Bluetooth, easy to operate
- Acquisition of speed and displacement
- Network disconnection cache monitoring and automatic retransmission
- Intelligent diagnosis algorithm
Technical Specifications
| Use | Monitoring system | |
| Acceleration | Number of Axes | 3 axes |
| Sensing Unit | MEMS | |
| Amplitude Range | ± 16 g peak | |
| Accuracy | ±5% (160 Hz) Z / X / Y axis | |
| Data acquisition | Acceleration Frequency Range | 5 Hz (±3dB) to 2 kHz (±3dB) |
| Acceleration Amplitude Range | ±16 g | |
| Measurement Interval | 20-minute index | |
| Output Mode | Total value, effective value | |
| Telecommunications | Bluetooth | Bluetooth 5.0 |
| Bluetooth Frequency | 2.4 GHz ISM band 2.4 GHz to 2.483 GHz | |
| Bluetooth Power | 2 dBm | |
| LoRa | 470 MHz to 510 MHz | |
| Battery | Battery Model | Replaceable DC 3.6 V disposable lithium |
| Life | It can work for 3 years according to the configuration definition | |
| Standards | EMC Standard | IEC 61326-1 |
| Wireless Spectrum | ETSI EN 300 328 | |
| Security | Meet the technical requirements of mic short-range radio equipment | |
| Explosion Proof Safety | ExiallCT4 Zone 0 IIC gas environment | |
| Authentication | Meet CE Requirementsr | |
| Output | Digital signal | |
| Amplifier Type | IDT | |
| Voltage – Supply | 5 V | |
| Output Type | 5 V | |
| Current – Supply | 0.3 mA | |
| Mounting Type | DIP | |
| Features | Low Voltage | |
| Current Supply (Max) | 0.5 | |
| Case | Plastic | |
| Output Mode | Total value, effective value | |
| Temperature Acquisition | Measuring Range | -40 °F to 248 °F (-40 °C to 120 °C), (The surface temperature of the equipment shall not be confused with the working temperature of the product. The working temperature is limited by the battery. The battery is a distance from the sensing part at the bottom) |
| Accuracy | 33.8 °F (1 °C) | |
| Operating Temperature | -13 °F to 185 °F (-25 °C to 85 °C) | |
| Working Conditions | Working Temperature | -40 °F to 158 °F (-40 °C to 70 °C), (Working at or beyond the limit temperature for a long time will affect the service life of the battery and even damage the monitor) |
| Mechanical Parameters | Corrosion Resistance | Stainless steel body, solution resistant PC material |
| Drop Resistance | No problem 3.28 ft (1 m) drop to concrete | |
| Body Material | 304 stainless steel base and reinforced impact resistant glass fiber PC upper cover | |
| IP Level | IP68 waterproof and dustproof grade | |
| Fixing Hole | M6 × 1 mm × 7 mm internal thread | |
| Overall Dimension | Height: 3.34 in (8.5 cm); Diameter: 1.69 in (4.3 cm) | |
| Weight | 8.04 oz (228 g) (including battery) | |
