Overview
GAO Tek 21.5 Inch Wall Rack Mount Rugged IP65 Waterproof Tablet Computer Touch Screen Panel Industrial All in One PC is a 21.5-inch Wall Rack Mount Rugged IP65 Waterproof Tablet Computer Touch Screen Panel Industrial All-in-One PC. This robust and durable industrial-grade tablet PC is designed to withstand harsh environments with its IP65 waterproof rating, ensuring protection against water and dust intrusion. Its wall rack mount design allows for convenient installation in various industrial settings. Equipped with a touch screen panel, this all-in-one PC provides intuitive and seamless user interaction. Ideal for industrial applications, this tablet computer is built to deliver reliable performance and efficiency in challenging conditions, making it a versatile and practical solution for industrial automation, control systems, and other demanding tasks.
Features
- 21.5″ Full HD 1920 x 1080 resolution TFT LCD screen.
- Integrated with low power Intel® Core™ i5-4210U Processor, 2.10 GHz,10W
- Fan less design.
- 4GB DDR2 RAM.
- 120GB SSD.
- 10 Points Capacitance Touch Screen
- Tempered glass for front panel, rugged and low-profile design.
- Stainless steel front bezel.
- Wide operational temperature range, 14 °F to 122 °F (-10°C to +50°C)
- RoHS compliant.
Technical Specifications
| LCD Screen | |
| Size | 21.5′ |
| Aspect Ratio | 16:09 |
| Pixel Pitch | 0.009 in x 0.009 in (0.24795 mm x 0.24795 mm) |
| Resolution | 1920 x 1080 (WSUVGA) View Angle |
| View Angle | View Angle 170° (H)/160° (V) |
| Brightness | 450/1000 nits (Optional) |
| Contrast Ratio | 1500:01:00 |
| Colours | 16.7 M (8 Bit) |
| Touch Screen | |
| Screen | 10-point Capacitance Touch |
| Active Area | 18.89 in x 10.68 in (479.84 mm x 271.30 mm) |
| Viewing Area | 18.80 in x 10.59 in (477.60 mm x 269.20 mm) |
| Screen Thickness | 0.15 in (3. 95mm) |
| Resolution | 16384 x 9600 |
| Response Time | Below 10 ms |
| Light Transmission | >80% |
| Touch Media | Finger |
| Durability | More than 10,000,000 single touch |
| MTBF | >60,000 hours |
| PC System | |
| Intel® Core™ i5-4210U Processor, 2.10 GHz | Quad Core Quad thread 2.1 GHz (Optional) 2 M L2 cache 35 W low TDP |
| Chipset | Intel® Core™ i5-4210 U Processor, 2.10 GHz |
| Memory | 4 GB DDR3L |
| I/O Interface | 2 x USB 2.0, 2 x USB 3.0, 2 x (RS232) 1 x 4 PIN 12 VCD 2 x FAN 1 x MINI-SATA 1 x MINI-PCIE 1 x ATA 1 x SIM 1 x LVDS/eDP |
| Sound Card | ALC662 chip, 6-channel sound card, front Audio pin |
| Hardware Detect | ITE8712, CPU detect Fan, system fan, voltage, temperature, etc. |
| Net Card | 10 to 100 to 1000 M adaptive network card |
| H.D. D | SSD 32 GB / 64 GB / 128 GB |
| Power requirement | +12 V,24 V |
| Rear Panel I/O | 1 x RJ-45 2 x 2.0 USB, 2 x 3.0 USB ports 1 x DC (in) 1 x HDMI AUDIO-OUT AUDIO-MIC |
| s Speaker | Power: 5 W x 2 |
| Quality Approval | |
| Fire-resistance | UL-94HB |
| Chemical-resistance | Active area of Touch is resistant for acetone, toluene, butanone, acetylacetone, methanol, acetic acid, gas, coal oil, and Vinegar. |
| Certificate | RoHS, FCC (Part 15) CE (EN55022 and EN55024) |
| Power Supply | |
| Power Input | 12/24 V DC (Optional) |
| Power Consumption | Approx. 65 Watts |
| Mount | VESA mount |
| Accessories 5 | AC Adapter, Power Cord |
