Key Features
- Rugged, compact design
- Operating frequency: 865 to 930 MHz
- Maximum performance and flexibility
- Circular polarization
- Antenna gain: 7.8 dBi
Technical Specifications
| Physical | |
| Dimensions | 250 mm L x 250 mm W x 58 mm D |
| Connector Type | SMA female, requires accessory cable to connect to reader, can be ordered separately |
| Connector Position | Rear |
| Mounting bracket | Available separately |
| Weight | 0.46 kg |
| Casing | Metal with plastic cover |
| Operational | |
| Freq. Range | 865 to 930 MHz (US and Canada, Europe, Australia, Japan and China) |
| Gain | 7.8 dBi |
| VSWR | from 1.07 : 1 to 1.19 : 1– for band 902 – 928 MHz; 1.21:1 – centre of EU band 865 – 868 MHz |
| Polarization | LHCP or RHCP |
| 3db Beam Width | 64° |
| Input Power | 34 dBm |
| Max Power | 5 watts |
| Environmental | |
| Operating Temperature | -0° C to +55° C (indoor use only) |
| Storage Temperature | -40 °C to +70° C |
Measured pattern of an antenna
Measured VSWR
Product Brochure
Download the brochure for this product.
