Technical Specifications
| Frequency | 865 MHz To 868 MHz,920 MHz To 925 MHz |
| Protocol | EPC C1 GEN2 Or ISO 18000-6C |
| Antenna Gain | Circular Antenna (5 dBi) |
| Read Or Write Range | Impinj R 2000 Module: 65.62 ft (20 m) (Tags And Environment Dependent) |
| Frequency | 13.56 MHz |
| Protocol | ISO 14443 A Or B & 15693, NFC-IP1, NFC-IP2 |
| Read Or Write Range | 1.18 in To 1.97 in (30 mm To 50 mm) |
| CPU | Cortex A73 2.0GHz Octa-Core |
| Operating System | Android 10.0 |
| Storage | 2 GB RAM Or 16 GB ROM Or 4 GB RAM Or 64 GB ROM, Micro SD (max 256 GB Expansion) |
| SDK | Handheld-Wireless Software Development Kit |
| Language | Java |
| Environment | Android Studio Or Eclipse |
| WWAN | TDD-LTE Band 38, 39, 40, 41; FDD-LTE Band 1, 2, 3, 4, 7, 17, 20; WCDMA (850 MHz Or 1900 MHz Or 2100 MHz); GSM Or GPRS Or Edge (850 MHz Or 900 MHz Or 1800 MHz Or 1900 MHz) |
| WLAN | 2.4 GHz Or 5.0 GHz Dual Frequency, IEEE 802.11 a Or b Or g Or n Or ac |
| WPAN | BT Class v 2.1+ EDR, BT v 3.0 + HS, BT v 4.2 |
| GPS | GPS (Embedded A-GPS), Accuracy Of 6.40 ft (5 m) |
| Resolution | Rear 13 Megapixel, Front 5.0 Megapixel (Standard) |
| Lens | Auto-focus With LED Flash |
| 2D CMOS Imager | Zebra SE 4710 Or Mindeo ME 5600 |
| Symbologies | PDF 417, Micro PDF 417, Composite, RSS, TLC-39, Data Matrix, QR Code, Micro QR Code, Aztec, Maxi Code, Postal Codes, US Post Net, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal etc. |
| Protocol | ISO 7816 |
| Baud Rate | 9600, 19200, 38400, 43000, 56000, 57600, 115200 |
| Slot | 2 Slots (maximum) |
| Expansions | 1 SIM, 1 TF 1 PSAM |
| Battery | Rechargeable li-ion Polymer, 3.8 V, 9000 mAh |
| Display | Gorilla Glass 3 9 H 5.5 in (13.97 cm) TFT-LCD (720×1440) Touch Screen With Backlight |
| Drop Specifications | 5 ft (1.5 m) Drop To Concrete Across The Operating Temperature Range |
| Sealing | IP 65, IEC Compliance |
| ESD | ± 15 kv Air Discharge, ± 8 kv Direct Discharge |
| Humidity | 5 % RH To 95 % RH (Non-Condensing) |
| Backlight | LED Backlight |
| Operating Temp. | -4 °F To +122 °F (-20 ℃ To +50 ℃) |
| Storage Temp. | -4 °F To +158 °F (-20 ℃ To +70 ℃) |
| Dimension | 6.53 in x 3.11 in x 1.22 in (± 0.07 in) (166 mm x 79 mm x 31 mm) ± 2 mm |
| Weight | 22.9 oz (650 g) (Including Battery & Wrist Strap) |
